With unparalleled reliability and reliability, and the FH14T power relay is a high-performance relay used in the installation of power systems and automated control, and it is essential in industrial control applications and in living appliances.

The FH14T Power Relay's features
High Switching Capability: The FH14T relay can switch contacts at a rate of 17A, making it appropriate for matters with moderate current.
UL Insulation Class: Class F, it complies high security requirements.
Eco-Friendly Product: Reliable, eco-friendly, and compliant with RoHS regulations.
Its small size (21.1 x 16.2 x 21.6 mm) makes integration and installation simple.

Product Specifications
One always open contact (1A), one normally closed contact (1B), plus a switched contact (1C) provide the contact arrangement.
Rated Load: 17A 250VAC.
Insulation Resistance: 100MΩ (500VDC).
Dielectric Withstand Voltage: Between open contacts 1000VAC for 1 minute; between contacts and coil 2500VAC for 1 minute.
Operation/Release Time: Operation time ≤15ms, release time ≤10ms.
Ambient Temperature: -40℃ to 85℃.
Humidity: 5% to 90%.

Application Range
The FH14T power relay is widely used in home appliances, industrial control, and other fields, becoming an ideal choice for control and protection in these areas due to its stable performance and high reliability.

Precautions
1.Anti-Drop: To maintain the product's initial performance parameters, avoid dropping it or exposing it to external impacts.
2. Voltage Requirements: The actual driving voltage should be between one and one and a half times the rated voltage; make sure the excitation voltage exceeds the rated value.
3. Environmental Adaptability: Plastic-sealed kinds are offered for contaminated context, while flux-proof types are recommended for clean ones.

Choosing FH14T means choosing an accurate and continuous power control system.
